Our Library never stops expanding. What are the most recent contributions to LabRulezICPMS Library in the week of 27th April 2026? Check out new documents from the field of spectroscopy/spectrometry and related techniques!
👉 SEARCH THE LARGEST REPOSITORY OF DOCUMENTS ABOUT SPECTROSCOPY/SPECTROMETRY RELATED TECHNIQUES
👉 Need info about different analytical techniques? Peek into LabRulezLCMS or LabRulezGCMS libraries.
This week we bring you application notes by Agilent Technologies, LECO, Shimadzu, and Thermo Fisher Scientific!
1. Agilent Technologies: Ethanol Impurity Analysis Using the Agilent Cary 3500 Flexible UV-Vis Spectrophotometer
The use of long-path-length cells in pharmaceutical QC
- Application note
- Full PDF for download
Ultraviolet-visible (UV-Vis) spectroscopy is a rapid, sensitive, and nondestructive test widely used in the pharmaceutical industry for quality control (QC). This method typically involves using a standard 10 mm path length cuvette to measure absorbance of materials, which can then be used in QC labs to quantify or qualify an analyte of interest.
In UV-Vis measurements, the photometric response of the spectrophotometer follows the Beer‑Lambert law, where a linear relationship exists between the sample absorbance and sample path length. The path length is the distance that the incident light travels through a sample. Increasing the cuvette path length from 10 to 50 mm increases the absorbance of a sample, aiding in more accurate quantification of components with low peak intensity. Alternatively, if the sample concentration is high and exceeds the linear dynamic detection range of the system, a cuvette with a shorter path length can be used instead.1
In the pharmaceutical industry, ethanol is widely used in manufacturing as a disinfectant, solvent, and preservative. Due to its amphipathic structure, ethanol can dissolve both hydrophilic and lipophilic substances, serving as a medium to dissolve key components for a broad spectrum of drug formulations. The dual nature of ethanol also allows it to inhibit microbial growth by disrupting cellular membranes and denaturing proteins, processes that are vital for disinfection and the preservation of medications.2
As a result, ethanol used in pharmaceutical manufacturing must comply with pharmacopeia standards to ensure drug safety, efficacy, and quality. The United States Pharmacopeia (USP)3, European Pharmacopoeia (EP)4, and Japanese Pharmacopoeia (JP)5 all specify using an ultraviolet absorption test to measure impurities in ethanol at designated wavelengths (Table 1). In this test, the absorption spectrum should show a steadily descending curve with no observable peaks or shoulders, which serve as qualitative indicators of impurities present in the sample. Since the impurities have low absorbance levels, the USP, EP, and JP require the use of a 50 mm cell to improve sensitivity and detection levels.
Conclusion
The Agilent Cary 3500 Flexible UV-Vis spectrophotometer with variable-path-length cell holder demonstrates exceptional performance in the measurement of ethanol impurities according to global pharmacopeia standards. This underscores the system's suitability for pharmaceutical‑grade quality control. Combined with Agilent Cary UV Workstation software and a 10-year xenon flash lamp replacement warranty, this system delivers a user-friendly interface and global pharmacopeia-compliant hardware (USP, EP, JP), providing long‑term stability and low maintenance. Optimized workflows enable precise, routine photometric quality checks to ensure products are in compliance with pharmaceutical-grade standards.
2. LECO: Determination of Nitrogen/Protein in Whey and Powdered Dairy Products
- Application note
- Full PDF for download
Two of the main types of proteins in milk are casein and whey. Whey protein is a co-product of cheese production and represents the water-soluble protein remaining in the solution after the milk has been acidified or a coagulation agent has been added. The removal of the non-soluble casein protein portion is referred to as curds. Whey protein is a common ingredient in many dietary supplements due to its availability, solubility, and unique functional characteristics.
The accurate and precise determination of protein in whey and powdered dairy products not only plays a role in the characterization of nutritional or dietary value in dairy products, but may also be key in determining the quality or category of the dairy product. Protein in whey and other dairy products is most commonly calculated using the measured Nitrogen in the sample and a protein factor multiplier (protein factors vary according to the sample matrix).
Instrument Model and Configuration
The LECO FP928 is a macro combustion Nitrogen/Protein determinator that utilizes a pure Oxygen environment in a high-temperature horizontal ceramic combustion furnace, utilizing ceramic boats designed to handle macro sample masses (~ 1.0 g). A thermoelectric cooler removes moisture from the combustion gases before they are collected in a ballast. The gases equilibrate and mix in the ballast before a representative aliquot (3 cm3 or 10 cm3 volume) of the gas is extracted and introduced into a flowing stream of inert carrier gas (Helium or Argon) for analysis. The aliquot of gas is carried through a heated reduction tube, filled with Copper, to convert Nitrogen Oxide combustion gas species (NOx) to Nitrogen (N2). The aliquot gas is then carried to a thermal conductivity cell (TC) for the detection of Nitrogen (N2).
Thermal conductivity detectors work by detecting changes in the thermal conductivity of the analyte gas compared to a reference/carrier gas. The greater the difference between the thermal conductivity of the carrier gas and the analyte gas, the greater the sensitivity of the detector. The FP928 supports either the use of Helium or Argon as the instrument's carrier gas. When used as a carrier gas, Helium provides the highest sensitivity, and the best performance at the lower limit of the Nitrogen range. The thermal conductivity difference between Argon and Nitrogen is not as great as the thermal conductivity difference between Helium and Nitrogen; therefore, the detector is inherently less sensitive when using Argon as a carrier gas.
TYPICAL RESULTS
Data was generated utilizing a linear, force through origin calibration using ~0.75 g of LECO 502-896 (Lot 1007) LCRM EDTA (9.59% N). The calibration was verified using ~0.1 g of LECO 502-688 (Lot 1004) LCRM Nicotinic Acid (11.37% N). Samples were weighed and analyzed at ~0.5 grams. A protein † factor of 6.38 was used for all samples to calculate the protein content.
3. Shimadzu: High-Temperature Gigacycle Fatigue Test of Inconel 718 and Element Distribution Measurement on a Fracture Surface
- Application note
- Full PDF for download
User Benefits
- Fatigue testing at 20 kHz can be performed using an ultrasonic fatigue testing machine, and 109 cycle fatigue tests can be completed in about 14 hours.
- High-temperature fatigue tests can be performed by using a combination of an ultrasonic fatigue testing system and an induction heating furnace.
- The origins of fatigue fractures and inclusions can be identified by observations and element distribution measurements using an electron probe microanalyzer.
Inconel 718 has excellent heat and corrosion resistance and high strength. Its mechanical properties can be maintained even under high-temperature environments, which is why it is used in harsh environments, such as in the jet engines and turbine blades in the aerospace industry, and in gas turbines and nuclear power plant parts in the energy industry. In these applications, long-term reliability is crucial, making fatigue testing essential. However, this can be time-consuming; for example, gigacycle fatigue testing exceeding 109 cycles takes three to four months at a frequency of 100 Hz when using a conventional fatigue testing machine. But with the USF-2000A ultrasonic fatigue testing system, tests performed at a frequency of 20 kHz can be completed in approximately 14 hours.
This article describes using the USF-2000A to perform gigacycle fatigue tests on Inconel 718 at 600 °C. In addition, the EPMA8050G, which is an electron probe microanalyzer (EPMA ), was used to observe the fatigue fracture surfaces and measure the element distribution.
Conclusion
Gigacycle fatigue tests were performed on Inconel 718 at 600 °C, using the USF-2000A ultrasonic fatigue testing system. Good results were obtained since the number of cycles to fractures fell in the range 106 to 109 for their respective loading conditions. The EPMA-8050G electron probe microanalyzer was used to perform elemental mapping analysis of fractures originating from inclusions, and the elements of the inclusions were identified.
4. Thermo Fisher Scientific: XPS depth profiling of coated nitrided steel using femtosecond laser ablation
- Application note
- Full PDF for download
X-ray photoelectron spectroscopy (XPS) is a powerful surface analysis technique that provides essential information about elemental composition along with chemical and electronic states. Depth profiling, a process in which material is repeatedly and sequentially analyzed with XPS and removed, provides access to buried features, layers, and interfaces. Traditional ion sputtering methods for depth profiling can, however, lead to preferential sputtering and chemical damage, impacting the reliability and accuracy of results. This is particularly problematic for complex, multi-layered structures and coatings, where it is crucial for the stoichiometry and chemical integrity to be maintained throughout the depth profile.
This application note explores the use of femtosecond laser ablation (fs-LA) as an alternative to conventional ion sputtering for XPS depth profiling. Specifically, this approach is used to analyze a nitrided steel surface coated with a titanium-doped molybdenum disulfide (MoS₂:Ti) layer, which was applied with physical vapor deposition (PVD). Nitriding is typically used in applications where durability is critical, such as in the production of gears, as it increases surface hardness and wear resistance. The addition of a MoS₂:Ti coating offers additional benefits such as enhanced lubrication and wear resistance. Molybdenum disulfide is well-known for its lubricating properties, and doping with titanium improves mechanical strength and adhesion to the substrate. Accurate depth profiling is essential for unraveling how these structures increase performance and for their further optimization and improvement.
Experimental
A Thermo Scientific™ Hypulse™ Surface Analysis System, equipped with both traditional ion sputtering and fs-LA capabilities, was utilized for the analysis. XPS data was collected in SnapShot mode using a 30 µm X-ray spot size. A 500 eV monoatomic Ar⁺ beam from a Thermo Scientific™ MAGCIS™ Dual Beam Ion Source was used for sputter depth profiling. The fs-LA depth profiles were generated using a 1,030-nm laser operating at a 160 fs pulse length. The pulse energy was increased from 83 µJ to 250 µJ when transitioning from the MoS₂:Ti coating into the bulk steel material.
Summary
XPS depth profiling with femtosecond laser ablation offers a robust alternative to traditional ion sputtering, particularly for materials sensitive to preferential sputtering and chemical damage. The technique provides accurate stoichiometric analysis and preserves chemical state information, making it ideal for complex, multi-layered structures with deeply buried interfaces. The fs-LA method can offer comparable depth resolution to ion sputtering while being able to profile greater depths in a fraction of the time.
This application note demonstrates the effectiveness of fs-LA in maintaining the chemical integrity of a nitrided steel material with a MoS₂:Ti coating throughout a depth profile, providing accurate and reliable results in a practical timeframe.
