DataApex Clarity Offline Chromatography Software

Clarity Offline allows users to import previously acquired data and to evaluate and prepare methods in regulated environment.

Clarity Offline allows users to import previously acquired data and to evaluate and prepare methods. This version cannot acquire data, but it can share data or even directly access (through LAN) projects of the <a href="https://lcms.labrulez.com/products/999">Clarity</a> and Clarity Lite software. With Clarity Offline users are able to work with acquired data on additional computers in the lab or at home. The software works with the same files and provides the same outputs (printing and exporting) as Clarity and Clarity Lite.
Clarity Offline is intended for use as additional software that supplements Clarity and Clarity Lite. It can also be used to evaluate data from other manufacturers&#39; CDS.
<blockquote>
Ask for <a href="https://www.dataapex.com/product/clarity-demo">Clarity Demo version</a> which allows you to get your hands on software before purchase
</blockquote>
<h3>Main features</h3>
<ul>
<li>21 CFR Part 11 compliance: Clarity Offline contains all functions (Electronic Signatures, User Accounts, Audit Trail, etc.) for compliance with the 21 CFR Part 11 directive of the FDA. Clarity Offline can be used for evaluation in regulated environments.
</li>
<li>Networked Solution: Clarity Offline can access files of Clarity and Clarity Lite installed on networked computers. This enables evaluation of chromatograms, development of new methods, and printing reports on additional computers in the laboratory.
</li>
<li>Education: An additional field of use is in education. Students can process chromatograms that have been acquired from Clarity connected to a chromatograph using their Clarity Offline license. Thus they do not need a Clarity full license just for data evaluation.
</li>
<li>Data processing and evaluation from other chromatography software: Clarity Offline allows the import of data from other chromatography software using text or AIA import function. This allows the user to process and evaluate chromatograms acquired by other chromatography software.
</li>
<li>Offsite computer: Clarity Offline can be installed on any Windows computer, giving you anytime access to your chromatographic data (USB hardware key is required).
</li>
<li>Language Localizations available: Useful for non-English speakers. At the moment, there are French, German, Russian, Spanish, and Chinese localizations available in a single installation package. Simply switch to your preferred language anytime.
</li>
</ul>
<a href="https://www.dataapex.com/controls">List of supported instruments</a>
<a href="https://www.dataapex.com/product/clarity-std-compatibility">Compatible Windows OS and Hardware</a>
<a href="https://www.dataapex.com/product/clarity-21cfr-compliance">Clarity 21 CFR Part 11 compliance</a>

DataApex EA - Elemental Analysis Extension for Clarity

Using features that are specific to EA Analysis, such as Standard Table, automatic weight input from analytical balance and other improvements, EA Extension provides an interactive and automated tool for determining the Carbon, Hydrogen, Nitrogen, Oxygen, and Sulfur (CHNS-O) content of unknowns.

<h3>The extension for elemental analysis</h3>
EA Extension is a software module for Elemental Analysis. Determining the Carbon, Hydrogen, Nitrogen, Oxygen, and Sulphur (CHNS-O) content of unknowns is one of the most basic and essential needs of any chemist. It provides a simplified version of the <a href="https://icpms.labrulez.com/products/999">Clarity</a> user interface that speeds up the workflow with elemental analyzers equipped with autosamplers. Its user interface is optimized for maximum efficiency in repetitive tasks. Using features that are specific to EA Analysis, such as Standard Table, automatic weight input from analytical balance and other improvements, EA Extension provides an interactive and automated tool for determining the Carbon, Hydrogen, Nitrogen, Oxygen, and Sulfur (CHNS-O) content of unknowns.
<h3>Main features</h3>
<ul>
<li>Calibration: Simplified work with template method and calibration. One setting is shared for all samples in the same sequence.
</li>
<li>Standard Table: For your convenience, the software contains Standard Table with a list of the most commonly used calibration standards and their elemental composition.
</li>
<li>Reporting: Clarity EA supports the printing of user defined protocols. Its configuration is saved in a report style, which defines the content and form through the printout. Protocols can be printed to the PDF file.
</li>
<li>Analytical balance: The Clarity Elemental Analysis Software provides direct interface with the analytical balance (Sartorius and Mettler). After weighing the sample, the operator presses the print key on the balance (or uses software instruction) to directly transfer the sample weight to the software sample information field thereby eliminating any possible transcription errors.
</li>
<li>Sequence Table: Measurement is managed using the Sequence Table. The Summary Table displays results clearly. ASCII and AIA data formats can be exported or imported directly.
</li>
<li>Database: Results can be exported in the .txt and .dbf format.
</li>
</ul>

Mestrelab Mnova Gears software

This comprehensive software suite, designed for building automation workflows, caters to your analytical data needs, spanning NMR, LC/GC-MS, and more.

<h3>Mnova Gears | Real-Time &amp; Batch processes</h3>
<h4>Automation Workflows for All Your Analytical Data Processes</h4>
Are you tired of the monotony of routine data processing? Mnova Gears (also known as Mgears) is here to free up your time for innovation and more engaging tasks. This comprehensive software suite, designed for building automation workflows, caters to your analytical data needs, spanning NMR, LC/GC-MS, and more. Simply set your analysis samples and SOPs, launch the process, and let Mnova Gears handle the rest. From data retrieval to processing and analysis, Mnova Gears effortlessly applies the methods and formulas you provide, presenting the results in comprehensive reports.
Experience the flexibility, seamless integration with your existing architecture, and the customizable nature of Mnova Gears. Like Mnova, it remains vendor-neutral, adapting to your unique requirements. Elevate your analytical data processes—automate with Mnova Gears!
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Mestrelab_Research_Mnova_Gears_Design_your_data_workflows_and_let_Mgears_do_the_rest_5771003702.jpg" alt="Mestrelab Research: Mnova Gears - Design your data workflows and let Mgears do the rest!"/>
<blockquote>
<h4><a href="http://www2.mestrelab.com/l/271522/2024-03-25/3nwsl4">Visit MestreLab Research Mnova Gears product page to learn more!</a></h4>
</blockquote>
<h4>What’s new in Mnova Gears 2.5?</h4>
Mnova Gears 2.5 has been released with Mnova 15 introducing a range of new capabilities:
<ul>
<li>New file copy option that copies the input files to the output folder without the need to open, process, or analyze them.</li>
<li>Ability to add chromatogram blind regions.</li>
<li>Improved data selection and auto-detection.</li>
<li>Capability to manage input data organized in multiple subfolders and generate sorted reports for each subfolder.</li>
<li>Heat map data visualization.</li>
<li>And other improvements that you can check in the complete changelog.</li>
</ul>
Upgrade to Mgears 2.5 now to explore these features and to unlock the full potential of data automation.
Also be sure you check our newest Mgears brick designed for <a href="http://www2.mestrelab.com/l/271522/2024-03-25/3nwskt">Affinity Selection Mass Spectrometry</a> analyses.
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Mestrelab_Research_Mnova_Gears_Increase_your_efficiency_using_automated_analysis_workflows_c9d3fb13e6.jpg" alt="Mestrelab Research: Mnova Gears - Increase your efficiency using automated analysis workflows!"/>
<h3>Mnova Gears products and how they relate to one another!</h3>
<h4><a href="http://www2.mestrelab.com/l/271522/2024-03-25/3nwsl4">Mnova Gears</a></h4>
<ul>
<li>Automation of multiple sample analysis </li>
<li>Batch and real time mode to generate documents for analysis</li>
</ul>
<h4><a href="http://www2.mestrelab.com/l/271522/2020-10-22/25htxg">Mnova MyGears</a></h4>
<ul>
<li>Automation of single sample analysis</li>
<li>Automation workflows on an open Mnova document</li>
</ul>
<h4><a href="http://www2.mestrelab.com/l/271522/2024-04-10/3p2gsd">Mnova Gears Bricks</a></h4>
<ul>
<li>Build automation workflows using the following Gears bricks</li>
</ul>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Mestrelab_Research_Mnova_Gears_1_b99a72ab8c.jpg" alt="Mestrelab Research: Mnova Gears products and how they relate to one another."/>
<blockquote>
<h4>Want to run a 45-day FREE trial?</h4>
<h4><a href="http://www2.mestrelab.com/l/271522/2024-04-10/3p2gsh">CONTACT AN EXPERT</a></h4>
</blockquote>
<h3>Intuitive 5-Step workflow!</h3>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Mestrelab_Research_Mnova_Gears_Intuitive_5_Step_workflow_9191e59a96.jpg" alt="Mestrelab Research: Mnova Gears - Intuitive 5-Step workflow."/>
<h4>Mnova Gears Benefits</h4>
<ul>
<li>Automate routine processes and workflows, saving valuable specialist time.</li>
<li>Create and manage end-to-end workflows seamlessly within a single tool.</li>
<li>Streamline multiple analytical workflows on a common, user-friendly platform.</li>
<li>Customize workflows by selecting components tailored to specific needs.</li>
<li>Enjoy flexibility and configurability, allowing seamless integration with existing infrastructure.</li>
<li>Collaborate with different systems in an unified environment due to vendor independence.</li>
<li>Leverage the familiarity with the Mnova interface to deploy and adopt automation solutions by your team without an extensive learning curve.</li>
<li>Benefit from expedited product support and development, consolidating all your automation analyses in one software suite.</li>
</ul>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Mestrelab_Research_Mnova_Gears_Mnova_Gears_Benefits_3186347cb7.jpg" alt="Mestrelab Research: Mnova Gears - Mnova Gears Benefits"/>
<h4>Mnova Gears Features</h4>
<h5>Powerful Automation Capabilities for Comprehensive Data Tasks</h5>
<ul>
<li>A user-friendly platform equipped with all essential controls for customizing data processes, covering input data, processing and analysis methods, design, and output generation.</li>
<li>A wide array of default features and options is available to maximize adaptation to customer needs.</li>
<li>Acceptance of templates and scripts for further customization; you can even construct your own automation bricks using scripting.</li>
<li>Details of your customization are stored in a settings file, easily shareable and importable.</li>
</ul>
<h5>Automatic Reporting and Archiving</h5>
<ul>
<li>Diverse output formats, including CSV, PDF, HTML, JSON, and Mnova formats.</li>
<li>Seamless adaptation to data organization standards by specifying requirements for correct data archiving (in a folder, database, ELN, etc.).</li>
<li>Easy workflows to automatically update historic data to new standards, ensuring consistency across years and sites.</li>
<li>Continuous support and updates: Contact the support team for specific import/export format requests.</li>
</ul>
<h5>A User-Friendly Result Viewer with Graphical Dashboards for Rapid and Easy Data Review</h5>
<ul>
<li>Effortless exploration of results with the Mgears Results Viewer, featuring graphical dashboards.</li>
<li>At-a-glance and by-exception reviews for quick and effective data analysis.</li>
<li>Smooth navigation through sample lists or well plates, facilitating the review of data and analyzed spectra.</li>
<li>Identification of samples not meeting specifications using graphics and warning flags, saving time on extensive scrutiny.</li>
<li>Swift recalculations and result updates.</li>
</ul>
<h4>Multi-Technique and Multi-Application Analytical Workflows</h4>
<ul>
<li>Multiple techniques supported: NMR, LC-MS, GC-MS, Chromatography, etc.</li>
<li>Mnova Gears has already proven its prowess with a broad range of applications spanning from discovery, R&amp;D, to manufacturing and quality control.</li>
<li>Available applications include structure verification, purity determination, mixture analysis, chemical reaction optimization, and affinity selection mass spectrometry analysis. Explore the <a href="http://www2.mestrelab.com/l/271522/2024-04-10/3p2gsd">full list of applications</a> for comprehensive coverage.</li>
</ul>
<h3>Markets</h3>
<h5>Academic, Government &amp; Industrial</h5>
<h4>PRACTICAL APPLICATIONS</h4>
<ul>
<li>Quality Control (NMR, Mass Spectrometry, etc)</li>
<li>Natural Product Dereplication by NMR</li>
<li>Reaction Monitoring by NMR</li>
<li>Quantitative NMR</li>
<li>Targeted mixtures analysis by NMR</li>
<li>Multi-technique reporting</li>
<li>Protein-ligand Interaction</li>
<li>Product ID confirmation</li>
<li>Structure verification</li>
<li>DNA Profiling by LCMS</li>
<li>Ligand-based drug screenings</li>
<li>Reaction Optimization (HTE)</li>
<li>Determination of solubility, lipophilicity</li>
<li>System Suitability testing (NMR, LCMS)</li>
<li>Compound separation and purification workflows</li>
</ul>

Mestrelab USP-ID software

USP-ID software combines high-quality chemical reference databases with smart algorithms for one-click, automated solutions by qNMR, giving scientists the tools to identify and quantify complex chemical mixtures.

<h3>Powerful qNMR analysis made easy</h3>
USP-ID software combines high-quality chemical reference databases with smart algorithms for one-click, automated solutions by qNMR, giving scientists the tools to identify and quantify complex chemical mixtures.
<blockquote>
<h3><a href="http://www2.mestrelab.com/l/271522/2024-03-25/3nwsnf">Visit MestreLab Research USP-ID software product page to learn more!</a></h3>
</blockquote>
<h4>Benefits of USP-ID</h4>
<ul>
<li>Easily identify chemicals and impurities – USP-ID automatically identifies, quantifies and labels a broad range of chemical components in complex mixtures. With just 10 minutes of video training NMR becomes more approachable to all.</li>
<li>Resolve overlapping peaks – Improve spectral interpretability with quantum-mechanical models based on USP reference standards and smart analytics. Identify and quantify chemicals, even when no single signal is distinct.</li>
<li>Customize your databases locally – Leverage USP-ID automation capabilities with drop-in support for models and databases that users create and own. USP can support with custom model development.</li>
</ul>
To learn more about NMR specifications compatible with USP-ID, <a href="https://go.usp.org/usp-id-factsheet">download the datasheet now</a>.
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Mestrelab_Research_Mestrelab_USP_ID_software_1_0ba1eed579.jpg" alt="Mestrelab Research: Mestrelab USP-ID software: (1) Automatic Chemical ID, (2) Detect Impurities, (3) Automatic Quantitation, (4) Report Generator, (5) Customizable Libraries, (6) Information Workspace, (7) Automatic Peak Labeling, (8) Multi-library analysis, (9) Selectable analytical methods."/>
<h4>Features include:</h4>
<ul>
<li>Automatic Chemical ID – The Confirm ID workspace enables automatic chemical identification by allowing users to screen samples against a broad library of references. Both targeted workflows where desired chemical references are selected by the user and non-targeted where no references are pre-selected by the user are supported.</li>
<li>Find Impurities – Find Impurities eliminates manual spectral impurity scans by identifying and labeling signals that do not correspond to a confirmed chemical. Select a signal in the Find Impurities workspace to have it highlighted in the spectral viewer for guided spectral review.</li>
<li>Automatic Quantitation – Determine quantities eliminates time consuming, manual integration of signals and enables fast quantification based on all matched signals by comparison to an internal standard of known concentration.</li>
<li>Report Generator – Generate shareable PDF reports that detail the reproducible analysis steps and results. Reports contain relevant tables of matched compounds and purity values.</li>
<li>Customizable Libraries – Custom Libraries are kept only on the local PC and can be used for the full range of automated NMR data analysis workflows. Drop in new custom libraries or models in the library manager.</li>
<li>Information Workspace – See current analysis results from Confirm ID, Find Impurities, and Determine Quantities in the information workspace found underneath the spectral viewer.</li>
<li>Automatic Peak Labeling – After Confirm ID runs, all identified peaks are automatically matched to compounds and labeled in the spectral viewer, making results easier to verify and share.</li>
<li>Multi-library analysis – Select one or multiple libraries for non-targeted spectral analysis. Confirm ID can search multiple libraries simultaneously for matching compounds, including custom libraries kept only on the local PC.</li>
<li>Selectable analytical methods – Different analysis methods are available for automatic chemical identification and can be selected from a dropdown in the information workspace. Users can modify and save analysis methods for future use.</li>
</ul>
USP-ID can be used with USP’s recently revised and published USP quality standards that facilitate the use of nuclear magnetic resonance (NMR) and quantitative NMR as analytical techniques, including for the control of impurities. These standards incude: USP-NF General Chapters <a href="https://online.uspnf.com/uspnf/current-document/1_GUID-B980A615-B451-42FF-AC40-4CB8B64163E3_4_en-US">Nuclear Magnetic Resonance Spectroscopy</a>, and <a href="https://online.uspnf.com/uspnf/current-document/1_GUID-D84DE004-6D63-48D4-BC58-90A1830C5484_1_en-US">Applications of Nuclear Magnetic Resonance Spectroscopy</a>. To further support stakeholder adoption of NMR and qNMR, USP Education offers <a href="https://uspharmacopeia.csod.com/catalog/CustomPage.aspx?id=221000380">free training and courses</a>, including “Drug Quality Control Applications for qNMR.”
The integration of USP-ID into Mnova does not imply approval, endorsement, or certification by USP of Mestrelab products, nor does it imply that any other brand or product was judged to be unsatisfactory or inadequate. As a standard setting organization, USP avoids providing endorsements that create conflicts of interest that interfere or appear to interfere with its impartiality and objectivity.

Mestrelab qNMR plugin for Mnova software

Quantitative NMR analysis made easy! A dedicated workflow developed to streamline qNMR.

<h3>Quantitative NMR analysis made easy!</h3>
A wide range of analysis types, from manual to assisted or fully automated batch processing, for all your qNMR concentration and purity determinations.
<h3>A dedicated workflow developed to streamline qNMR!</h3>
Dealing with big batches of samples routinely? Automate your Purity and Concentration data workflows from end to end with our dedicated Mnova Gears solutions. Please check <a href="https://mestrelab.com/software/mnova-gears-purity/">Gears Purity</a> and <a href="https://mestrelab.com/software/mnova-gears-concentration/">Gears Concentration</a> for more information.
<blockquote>
<h3><a href="http://www2.mestrelab.com/l/271522/2024-05-02/3p9fs2">Visit MestreLab Research qNMR product page to learn more!</a></h3>
</blockquote>
Mnova qNMR is FREE FOR ACADEMIC LICENSES with an Mnova NMR license.
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Mestrelab_Research_Mestrelab_q_NMR_plugin_for_Mnova_software_Wide_range_of_quantitative_analysis_from_manual_analysis_to_assisted_automated_batch_processing_ac555ce417.jpg" alt="Mestrelab Research: Mestrelab qNMR plugin for Mnova software - Wide range of quantitative analysis from manual analysis to assisted automated batch processing."/>
<h3>What’s new in Mnova qNMR 3.2?</h3>
The new version of this qNMR plugin has been released with Mnova 14.3.2 and brings a number improvements together with its related Gears automation workflows listed below:
<h4>qNMR:</h4>
<ul>
<li>Updated parameter names for References to enhance user-friendliness: Reference, Reference Name, and RN</li>
</ul>
<h4>Gears Purity:</h4>
<ul>
<li>Additional methods for extracting molecular weight<ul>
<li>From the molecule in the document, if it exists</li>
<li>From the SMILES text in the parameters table, if it exists</li>
<li>From “MW” or “Molecular Weight” fields in the parameters, if they exist</li>
</ul>
</li>
</ul>
<h4>Gears Concentration:</h4>
<ul>
<li>Increased reporting choices available</li>
<li>Added units to the average concentration and CCF values in the report</li>
<li>Reconfigured the settings layout dialogue to enhance visualization</li>
</ul>
<h3>qNMR Highlights</h3>
<ul>
<li>Works on the basis of identified multiplets for a compound, and the number of Hs for each.</li>
<li>A “response factor” is determined for a particular instrument and experimental setup, and is used without further reference.</li>
<li>Automatic detection of all peaks to be excluded from the analysis: residual protic solvent, water, impurities.</li>
<li>Save and reuse optimized analysis parameters.</li>
<li>Easily manage replicate samples.</li>
<li>Validated against a dataset that was analysed by hand, by an expert.</li>
<li>For purity, input data for your own certified reference standard compounds.</li>
<li>Define a Standard Operating Procedure (SOP) that can be used by others.</li>
</ul>
<h3>qNMR Features</h3>
<h4>CONFIGURE THE CONCENTRATION DETERMINATION METHOD</h4>
Configure the concentration determination method to use a “concentration conversion factor” (CCF), an artificial signal, or the residual solvent signal. If necessary, automatically compensate for changes in the receiver gain or number of scans.
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Mestrelab_Research_Mestrelab_q_NMR_plugin_for_Mnova_software_CONFIGURE_THE_CONCENTRATION_DETERMINATION_METHOD_a2dfaad039.jpg" alt="Mestrelab Research: Mestrelab qNMR plugin for Mnova software - Configure the concentration determination method"/>
<h4>PURITY DETERMINATIONS</h4>
This module uses the Concentration “engine”, and therefore has all its features. However, this capability has been built to make NMR “Purity” (a.k.a. “Potency”) measurements simple and accurate. As an aside, the same basic functionality can be used to measure salt ratios, and solvent contamination levels.
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Mestrelab_Research_Mestrelab_q_NMR_plugin_for_Mnova_software_PURITY_DETERMINATIONS_60305d42b5.jpg" alt="Mestrelab Research: Mestrelab qNMR plugin for Mnova software - Purity determinations"/>
<h4>‘ONE CLICK’ Q-NMR (PURITY)</h4>
Optimised tool to obtain your Purity results in one single click using the ‘Advised Analysis’ button. This feature firstly will find your parameters (molecular weight, sample weight, reference compound etc.) Then it will apply optimized settings to carry out the NMR analysis and finally calculate your compounds purity.
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Mestrelab_Research_Mestrelab_q_NMR_plugin_for_Mnova_software_ONE_CLICK_Q_NMR_PURITY_75b5ff015c.jpg" alt="Mestrelab Research: Mestrelab qNMR plugin for Mnova software - ‘One click’ q-NMR (purity)"/>
<h4>ASSISTED BY STANDARDIZED OPERATIONS</h4>
By saving a procedure, easily work with repetitions, or create a SOP for others to always use. The automatic multiplet selection can make the analysis so simple that the hardest task is entering relevant sample-to-sample specific details!
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Mestrelab_Research_Mestrelab_q_NMR_plugin_for_Mnova_software_ASSISTED_BY_STANDARDIZED_OPERATIONS_83ce2ffffe.jpg" alt="Mestrelab Research: Mestrelab qNMR plugin for Mnova software - Assisted by standardized operations"/>
<h3>qNMR Users</h3>
<ul>
<li>Active Pharmaceutical Ingredients (APIs)</li>
<li>Drug analysis</li>
<li>Natural products</li>
<li>Pharmaceutical compound libraries</li>
<li>Forensic analysis</li>
<li>Food sciences and many more!</li>
</ul>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Mestrelab_Research_Mestrelab_q_NMR_plugin_for_Mnova_software_q_NMR_Users_e75d3ba308.jpg" alt="Mestrelab Research: Mestrelab qNMR plugin for Mnova software - qNMR Users."/>
<h3>Case Studies</h3>
<h4><a href="https://mestrelab.com/automated-qnmr-data-processing-and-analysis-in-the-behind-the-scenes-of-fragment-based-drug-discovery-case-study/">Automated qNMR data processing and analysis in the behind the scenes of fragment-based drug discovery</a></h4>
Bringing new drugs into the market is a long, complex process that often requires several years of investigation and considerable human, technological, and economic resources. In the labs of the Cancer Research UK Cancer Therapeutics Unit at The Institute of Cancer Research, London, a Fragment-Based Drug Discovery (FBDD) program has been established for screening and identifying lead compounds with potential therapeutic effects that may serve as starting points for the development of potent drug candidates… <a href="https://mestrelab.com/automated-qnmr-data-processing-and-analysis-in-the-behind-the-scenes-of-fragment-based-drug-discovery-case-study/">Continue reading</a>

Mestrelab NMR Predict plugin for Mnova software

 Accurate prediction of ¹H and ¹³C NMR spectra from a chemical structure. Mnova NMR Predict calculates accurate and precise NMR chemical shifts.

<h3>Accurate prediction of ¹H and ¹³C NMR spectra from a chemical structure.</h3>
<blockquote>
<h3><a href="http://www2.mestrelab.com/l/271522/2024-05-02/3p9fry">Visit MestreLab Research NMR Predict product page to learn more!</a></h3>
</blockquote>
Mnova NMR Predict calculates accurate and precise NMR chemical shifts using a novel procedure that combines several prediction engines in a constructive way. This method is called Ensemble NMR Prediction and uses several Machine Learning methods in combination with the well-knonwn Increments and HOSE-code algorithms developed by Modgraph Consultants. Prediction of chemical shifts of other nuclides is also available.
To complement the article about Ensemble NMR Prediction you can also read a blog post about ¹H data <a href="http://nmr-analysis.blogspot.com/2019/05/1h-nmr-prediction-unity-creates-strength.html">here</a>.
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Mestrelab_Research_Mestrelab_NMR_Predict_plugin_for_Mnova_software_Easily_combine_and_compare_experimental_and_predicted_data_as_part_of_your_workflow_1_d382f3c286.jpg" alt="Mestrelab Research: Mestrelab NMR Predict plugin for Mnova software - Easily combine and compare experimental and predicted data as part of your workflow."/>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Mestrelab_Research_Mestrelab_NMR_Predict_plugin_for_Mnova_software_Easily_combine_and_compare_experimental_and_predicted_data_as_part_of_your_workflow_2_54bdb23368.jpg" alt="Mestrelab Research: Mestrelab NMR Predict plugin for Mnova software - Easily combine and compare experimental and predicted data as part of your workflow."/>
<h4>NMR Predict Highlights</h4>
<ul>
<li>Compute and display accurate chemical shifts for ¹H, ¹³C, and other nuclides (¹¹B, ¹⁵N,¹⁷O, ¹⁹F, ²⁹Si, ³¹P) as well as J(HH), J(HF), J(HP), J(CF) and J(CP).</li>
<li>Predicted ¹H-NMR spectra are synthesized using a rigorous quantum mechanism approach that takes into account strong coupling effects.</li>
<li>If the experimental spectrum is available, prediction will use the same experimental conditions (e.g. solvent and spectral properties: spectral width, spectrometer frequency, chemical shift reference, digital number of points, etc.)</li>
<li>Train your predictions by building your NMR databases from already assigned molecular structures.</li>
<li>Ability to drill-down user assigned ¹H and ¹³C experimental data.</li>
<li>Each predicted value is accompanied by its confidence interval.</li>
</ul>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Mestrelab_Research_Mestrelab_NMR_Predict_plugin_for_Mnova_software_Make_better_decisions_for_your_spectra_faster_80045b0ee3.jpg" alt="Mestrelab Research: Mestrelab NMR Predict plugin for Mnova software - Make better decisions for your spectra faster!"/>
<h3>Markets</h3>
<h4>Academic, Government &amp; Industrial</h4>
<ul>
<li>Pharmaceutical, chemical and food industries and QC environments</li>
<li>Research and NMR teaching in Academia</li>
<li>Suitable for individual users, research groups as well as large institutions and companies</li>
</ul>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Mestrelab_Research_Mestrelab_NMR_Predict_plugin_for_Mnova_software_Users_932a7dd0ef.jpg" alt="Mestrelab Research: Mestrelab NMR Predict plugin for Mnova software - Users."/>

Watrex SCI-AQUA ROWAPUR BASIC Water Purification System

Fully automatic system for the preparation of pure water based on reverse osmosis. Reverse osmosis membrane is protected by three-stage pre-filtration consisting of sediment filter and two carbon adsorption filters.

Fully automatic system for the preparation of pure water based on reverse osmosis. Reverse osmosis membrane is protected by three-stage pre-filtration consisting of sediment filter and two carbon adsorption filters.Watrex SCI-AQUA BASIC is driven by water pressure from water distribution network, it does not require electric power. It prepares water free of mechanical impurities, chlorine, 95-99% of all dissolved substances are removed.&nbsp;Depending on input water composition and supply pressure the output water has a specific conductivity in the range of 10-20 µS/cm.Price: <bdi>384&nbsp;€</bdi> ex. VAT<h4>Features</h4><ul><li>Removes 95 – 99% of dissolved substances</li><li>Typical specific conductivity of produced water 10 – 20 µS/cm</li><li>6 to 12 months filters lifetime</li><li>2 – 5 years RO membrane lifetime</li><li>No electricity is required for operation</li><li>Supplied from water distribution network</li></ul><h4>Technical specification</h4><ul><li>Daily production capacity: 50 – 70 liters</li><li>Input water pressure: 0,3 – 0,7 MPa</li><li>Input water temperature: &lt; 35 °C</li><li>Maximum input water TDS: 1200 mg/l</li></ul><img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Watrex_Water_purification_systems_8810a2c48a.jpg" alt="Watrex: Water purification systems" srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_Watrex_Water_purification_systems_8810a2c48a.jpg 245w," sizes="100vw" width="2286" height="1130">Basic requirements for laboratory operations include the easy availability of pure laboratory water in the necessary quantity and quality. Distillation, a popular technique for producing purified water in the past, has virtually completely supplanted by less energy-intensive and operationally dependable alternatives today. Reverse osmosis is the foundation of the majority of contemporary systems for producing purified water; in reality, this principle is supplemented with adsorption, ion exchange, filtration, ultrafiltration, and other physical-chemical techniques.

Watrex SCI-AQUA ROWAPUR DEMI 90 Water Purification System

Fully automatic system for the preparation of clean water based on reverse osmosis combined with purification by a mixed ion exchanger.

Fully automatic system for the preparation of clean water based on reverse osmosis combined with purification by a mixed ion exchanger. Reverse osmosis membrane is protected by two-stage pre-filtration consisting of sediment and carbon filter.Watrex ROWAPUR DEMI is driven by water pressure from water distribution network, it does not require electric power.The output water has a specific conductivity less than &lt;1 µS/cm. The system includes a conductivity tester with optical indication of output water quality.Price: <bdi>761 €</bdi> ex. VAT<h4>Features</h4><ul><li>Specific conductivity of produced water &lt;1 µS/cm</li><li>6 to 12 months filters lifetime</li><li>2 – 5 years RO membrane lifetime</li><li>1000 – 2000 liters polishing filter capacity</li><li>No electricity is required for operation</li><li>Supplied from water distribution network</li></ul><h4>Technical specification</h4><ul><li>Specific conductivity of produced water: &lt; 1 µS/cm</li><li>Daily production capacity:&nbsp;up to 90 liters</li><li>Input water pressure:&nbsp;0,3 – 0,7 MPa</li><li>Input water temperature:&nbsp;&lt; 35 °C</li><li>Maximum input water TDS:&nbsp;1200 mg/l</li></ul><img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Watrex_Water_purification_systems_8810a2c48a.jpg" alt="Watrex: Water purification systems" srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_Watrex_Water_purification_systems_8810a2c48a.jpg 245w," sizes="100vw" width="2286" height="1130">Basic requirements for laboratory operations include the easy availability of pure laboratory water in the necessary quantity and quality. Distillation, a popular technique for producing purified water in the past, has virtually completely supplanted by less energy-intensive and operationally dependable alternatives today. Reverse osmosis is the foundation of the majority of contemporary systems for producing purified water; in reality, this principle is supplemented with adsorption, ion exchange, filtration, ultrafiltration, and other physical-chemical techniques.

Watrex SCI-AQUA ROWAPUR DEMI 180 Water Purification System

Fully automatic system for the preparation of clean water based on reverse osmosis combined with purification by a mixed ion exchanger. Reverse osmosis membrane is protected by two-stage pre-filtration consisting of sediment and carbon filter.Watrex ROWAPUR DEMI is driven by water pressure from water distribution network, it does not require electric power.The output water has a specific conductivity less than &lt;1 µS/cm. The system includes a conductivity tester with optical indication of output water quality.Price: 833<bdi> €</bdi> ex. VAT<h4>Features</h4><ul><li>Specific conductivity of produced water &lt;1 µS/cm</li><li>6 to 12 months filters lifetime</li><li>2 – 5 years RO membrane lifetime</li><li>1000 – 2000 liters polishing filter capacity</li><li>No electricity is required for operation</li><li>Supplied from water distribution network</li></ul><h4>Technical specification</h4><ul><li>Specific conductivity of produced water: &lt; 1 µS/cm</li><li>Daily production capacity:&nbsp;up to 180 liters</li><li>Input water pressure:&nbsp;0,3 – 0,7 MPa</li><li>Input water temperature:&nbsp;&lt; 35 °C</li><li>Maximum input water TDS:&nbsp;1200 mg/l</li></ul><img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Watrex_Water_purification_systems_8810a2c48a.jpg" alt="Watrex: Water purification systems" srcset="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/thumbnail_Watrex_Water_purification_systems_8810a2c48a.jpg 245w," sizes="100vw" width="2286" height="1130">Basic requirements for laboratory operations include the easy availability of pure laboratory water in the necessary quantity and quality. Distillation, a popular technique for producing purified water in the past, has virtually completely supplanted by less energy-intensive and operationally dependable alternatives today. Reverse osmosis is the foundation of the majority of contemporary systems for producing purified water; in reality, this principle is supplemented with adsorption, ion exchange, filtration, ultrafiltration, and other physical-chemical techniques.

DataApex Clarity Chromatography Software

Clarity is a chromatography data software for data acquisition, processing, and instrument control in regulated environment. Clarity is a flexible solution for devices from different vendors, supporting different applications.

Optional control modules provide integrated control of selected instruments such as GCs, LCs, pumps, detectors, autosamplers, etc. Extensions provide functions for specific separation techniques or calculations such as PDA, GPC analysis, Mass spectrometry, or SST. Clarity can run in English, French, German, Russian, Spanish, and Chinese language. Support technicians and developers are close to their users and ready to provide extensive Support from DataApex.
<blockquote>
Ask for <a href="https://www.dataapex.com/product/clarity-demo">Clarity Demo version</a> which allows you to get your hands on software before purchase
</blockquote>
<h3>Main features</h3>
<ul>
<li>Measuring: Simultaneous data acquisition from up to four independent chromatographs, each chromatograph can acquire data from up to 32 detectors.
</li>
<li>Integration: There is an extensive possibility to modify chromatograms. The chromatogram can be changed by entering global parameters or interactively through direct graphic modification of the baseline.
</li>
<li>Overlay: Simultaneously displays a virtually unlimited number of chromatograms and their mathematical modification; for example, mutual deductions or derivations of any order.
</li>
<li>Calibration: Internal and external standard calculation methods, calibration of groups of peaks, and reference peaks method for better identification.
</li>
<li>Wide range of supported instruments: Control modules in Clarity allow users to control various instruments in their lab. See our growing <a href="https://www.dataapex.com/controls">List of supported instruments</a>.
</li>
<li>Extensions completing your workflow: Clarity Extensions integrates your workflow into one application. GPC calculations, PDA data processing, gas or detailed hydrocarbon analyses according to selected norms, and much more.
</li>
<li>Automated measuring support: Sequence tables for any set of samples with or without an autosampler.
</li>
<li>Postrun: Automatically displays, prints, exports, and starts other programs after the completion of a measurement.
</li>
<li>Summary result tables: Displays and prints selected results from all simultaneously displayed chromatograms.
</li>
<li>User settings: User selects parameters for peak display and the specification for axes, including color from an extensive array of color settings. Text labels and lines, either as part of the area or anchored to a chromatogram, may also be inserted.
</li>
<li>Export: Optional exportation of all results, with or without the chromatogram, in various formats, into a file or clipboard.
</li>
<li>Import: Imports chromatograms or mathematical curves, which have been saved in text or AIA formats, from other programs.
</li>
<li>LIMS: Clarity offers connectivity with LIMS, both for sample submission and result output. This can be done via convenient ASCII transfers.
</li>
<li>Method and calibration history: Each chromatogram can easily be displayed under the same conditions as when it was printed, exported, or saved.
</li>
<li>Column performance: Calculations of peaks in terms of symmetry, efficiency, resolution; all by several methods (tangent, moments, etc.).
</li>
<li>Batch: Automatically batch processes, displays, exports, or prints any number of chromatograms.
</li>
<li>User calculations: Users can define custom calculations in the Result and Summary tables. Using the integrated editor, you can create your own columns from original columns and individual mathematical functions.
</li>
<li>User accounts: Sets up access rights and passwords (including their parameters, e.g., minimum length, validity, etc.). Each user can define his or her own appearance of the software.
</li>
<li>Audit trail: Records selected events and operations into a special file. Records selected operations directly into a chromatogram.
</li>
<li>Electronic signature: Each chromatogram can be signed electronically. Signature selection is based on the username or the signature certificate.
</li>
<li>Networked Solution: Clarity chromatography software files can be accessed from networked computers using Clarity Offline software. This enables the offline evaluation of chromatograms, development of new methods, and printing reports. See the <a href="https://gcms.labrulez.com/products/1000">Clarity Offline</a> for more details.
</li>
<li>Language Localizations available: Useful for non-English speakers. At the moment, there are French, German, Russian, Spanish, and Chinese localizations available in a single installation package. Simply switch to your preferred language anytime.
</li>
<li>Competitive approach: The chromatography market offers many specialized HPLC data systems or GC data systems; these are often provided with the purchased instrument. It is usually complicated to integrate such software into the workflow of the laboratory since they do not enable direct control of additional instruments. Compared to other small-scale solutions, Clarity offers a wide range of directly controlled instruments as well as optional Extensions for specific separation techniques. On the other hand, complex solutions with a wide scope of features and scalable design are quite expensive, which is a limiting factor for many customers. Another drawback of the large solutions is their complexity which imposes high demands on users. Compared to this, Clarity represents a scalable medium-ranged solution with a steep learning curve and competitive prices.
</li>
</ul>
<h3>Clarity configurations examples</h3>
<h4>One chromatograph with two detectors</h4>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Data_Apex_Clarity_Chromatograficky_Software_Clarity_configurations_examples_One_chromatograph_with_two_detectors_ae482b83b8/DataApex-Clarity-Chromatograficky-Software-Clarity-configurations-examples-One-chromatograph-with-two-detectors.jpg" alt="DataApex Clarity Chromatography Software: Clarity configurations examples - One chromatograph with two detectors.jpg"/>
<ul>
<li>The HPLC measures on two detectors. Clarity will acquire two separate signals sharing a common timebase (synchronized START/STOP). A resulting chromatogram will contain two signals.</li>
</ul>
<h4>Two chromatographs, one with multiple detectors</h4>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Data_Apex_Clarity_Chromatograficky_Software_Clarity_configurations_examples_Two_chromatographs_one_with_multiple_detectors_b21dc07faf/DataApex-Clarity-Chromatograficky-Software-Clarity-configurations-examples-Two-chromatographs-one-with-multiple-detectors.jpg" alt="DataApex Clarity Chromatography Software: Clarity configurations examples - Two chromatographs, one with multiple detectors.jpg"/>
<ul>
<li>This example displays a configuration with two chromatography systems (GC + HPLC) where the HPLC system uses multiple detectors. All the detectors attached to the HPLC Instrument will share common timebase (synchronized START/STOP). The GC detector will be independent.</li>
</ul>
<h4>Two chromatographs, one digital control</h4>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Data_Apex_Clarity_Chromatograficky_Software_Clarity_configurations_examples_Two_chromatographs_one_digital_control_1bf9cec334/DataApex-Clarity-Chromatograficky-Software-Clarity-configurations-examples-Two-chromatographs-one-digital-control.jpg" alt="DataApex Clarity Chromatography Software: Clarity configurations examples - Two chromatographs, one digital control.jpg"/> This example displays a configuration with two chromatography systems (GC + LC). The GC is connected and controlled via digital interface *, using a GC Control appropriate module.
<h4>Four chromatographs with autosampler each</h4>
<img src="https://storage.googleapis.com/labrulez-bucket-strapi-h3hsga3/Data_Apex_Clarity_Chromatograficky_Software_Clarity_configurations_examples_Four_chromatographs_with_autosampler_each_945873d808/DataApex-Clarity-Chromatograficky-Software-Clarity-configurations-examples-Four-chromatographs-with-autosampler-each.jpg" alt="DataApex Clarity Chromatography Software: Clarity configurations examples - Four chromatographs with autosampler each.jpg"/>
<ul>
<li>This example displays a configuration with two chromatography systems (GC + LC). The GC is connected and controlled via digital interface *, using a GC Control appropriate module.</li>
</ul>
<a href="https://www.dataapex.com/controls">List of supported instruments</a>
<a href="https://www.dataapex.com/product/clarity-std-compatibility">Compatible Windows OS and Hardware</a>
<a href="https://www.dataapex.com/product/clarity-21cfr-compliance">Clarity 21 CFR Part 11 compliance</a>

Related content

News from LabRulezICPMS Library - Week 40, 2024

LA-ICPMS for In Situ U–Th Dating of Holocene Stalagmites

Webinars LabRulezICPMS Week 41/2024
