Agilent Cary 3500 UV-Vis Compact, G9864A (Refurbished)

The Agilent Cary 3500 Compact UV-Vis is a double-beam UV-Vis spectrophotometer designed for accurate absorbance, concentration, kinetic, and temperature-controlled measurements in both research and routine laboratories. Featuring an integrated air-cooled Peltier system, a xenon flash lamp, and a modular architecture, it delivers high analytical performance with minimal maintenance. The instrument is ready for regulated environments and supports data integrity through Agilent OpenLab software.

Key Features

• Double-beam UV-Vis spectrophotometer for research and routine analysis
• Ambient and temperature-controlled measurements using an integrated air-cooled Peltier system
• Xenon flash lamp with instant start-up and no warm-up time
• Highly collimated beam (<1.5 mm) for accurate low-volume measurements
• Up to 250 data points per second for detailed kinetic experiments
• More than 50 built-in calculations with automatic method integration
• Modular platform supporting future application-specific upgrades
• Cary UV Workstation software with optional Agilent OpenLab integration
• Supports FDA 21 CFR Part 11, EU Annex 11, GAMP5, ISO/IEC 17025, and EPA 40 CFR Part 160 compliance requirements
• My Green Lab ACT certified for reduced environmental impact

Technical Specifications

Optical System

• Double-beam optical design
• Wavelength range: 190–1100 nm
• Spectral bandwidth: 0.1–5.0 nm
• Photometric range: 4 Abs
• Maximum scanning speed: 150,000 nm/min
• Xenon flash lamp (250 Hz)
• 10-year warranty on the xenon lamp for new instruments

Temperature-Controlled Measurements

• Integrated air-cooled Peltier temperature control
• Temperature range: 0 to 110 °C
• Temperature ramp rate up to 40 °C/min
• Direct temperature measurement inside the cuvette using Cary digital temperature probes
• No external water cooling required

Software and Data Management

• Cary UV Workstation software
• Optional Agilent OpenLab Software Suite integration
• Applications for absorbance, wavelength scanning, concentration, kinetics, and temperature-controlled measurements
• More than 50 built-in calculations
• Secure local or centralized electronic data storage
• Electronic signatures, audit trails, and user management with OpenLab

Mechanical Specifications

• Dimensions (W × D × H): 445 × 435 × 280 mm
• Weight: 24 kg
• Power requirements: 100–240 VAC, 50/60 Hz
• Measurement height (Z-height): 15 mm
